4x156mm to 4x156mm PCD (Vehicle/ Wheel Bolt Pattern), M12x1.5 Thread Pitch (34 ± 0.3 mm Thread Length), 131mm hub bore, 4pcs 2"
ORION MOTOR TECH WHEEL SPACERS widen your all-terrain or ultimate terrain vehicle's wheelbase to improve stability handling through tight turns over rough trails. Developed with specialized aluminum alloy through an innovative forging technique, they are wrought with CNC technology for perfected coplanar surfacing. Heat-treated and anodized for extra-strength and oxidation resistance, OMT wheel spacers widen your vehicle’s stance for enhanced driving precision.
Specifications
- Material: 6061-T6 Billet Aluminum, 35CrMo Steel, AISI A3 Steel
- Color: Silver
- Vehicle Bolt Pattern: 4 x 6.1 in. (4x156 mm)
- Tire Bolt Pattern: 4 x 6.1 in. (4x156 mm)
- Thread Size: M12x1.5
- Center Bore: 5.1 in. (131 mm)
- Thickness: 2 in. (50.8 mm)
- Package Weight: 20 lb. (9 kg)
- Warranty: 1 Year
To use this wheel adapter kit, make sure that your wheels' center bores are 131 mm (5.1 in.) or smaller; the bolt patterns on your vehicle and tires are 4x6.1" (4x156 mm); and your vehicle's current studs protrude less than 2 inches (50.8 mm). These rugged spacers are compatible with:
- Polaris Ranger (2013-Present)
- Polaris RZR High Performance S 900 (2015-Present)
- Polaris RZR Trail 900 (2015-Present)
- Polaris RZR Trail 900 XC (2015-Present)
- Polaris RZR XP 1000 (2014-Present)
Parts List
- 4 x Wheel Spacers
- 16 x Studs (M12x1.5)
- 2 x Wrench Sockets
- 2 x Tubes of Adhesive
- 1 x Instructions
DETAILED FUNCTION OF WHEEL SPACERS
IMPROVE VEHICLE STABILITY
Extra Safety: Wheel spacers widen your vehicle wheelbase to increase stability and enhance resistance to side roll-over. Added balance provides extra control for experienced riders and additional safety for younger or less experienced riders.
Increase Traction: Wheel spacers increase tire to frame clearance allowing installation of wider wheels and high-traction mud, rock, or snow tires.
IMPORTANT NOTES:
Professional installation is recommended. Alignment is necessary after installation; this will prevent any wobble or vibration from occurring. Avoid an impact wrench. Improper usage may cause lug nuts/bolts to break or loosen while driving, which can cause accidents or injury. Make sure you get 5-7 turns before tightening. Retorque all lug nuts/bolts after 25-50 miles of driving, then again after 1,000-2,000 miles. The back of the adapter must sit flush against the vehicle’s hub. Check for rust on the inner hub and wheel while installing these Hub centric wheel spacers. If the studs pass the adapter’s face, you will need to grind/cut them shorter (This only applies to 1.5" adapters & smaller).
