The Toyota FJ Cruiser is known as one of the most dependable off-road SUVs, and many people absolutely love it. Its style is bold, the chassis is rugged, and it has a powerful V6 engine. The FJ Cruiser is also a popular choice for those car owners who want to customize their SUV with aftermarket upgrades.
If you are one of them, and you plan to customize your Toyota FJ Cruiser by adding some wheel spacers, for example, you need to learn more about the Toyota FJ Cruiser bolt pattern.
This article has all the info you will need to get started. Here is a detailed presentation of the Toyota FJ Cruiser bolt pattern:
What is the FJ Cruiser Wheel Bolt Pattern?
The Toyota FJ Cruiser bolt pattern is 6x139.7 mm, or, if you are using inches, 6x5.5 inches. This tells you two things: there are six lug holes, and the diameter of the circle they form is 139.7 millimeters (or 5.5 inches).
Toyota FJ Cruiser Wheel Specifications
- Bolt Pattern: 6x139.7 mm (6 bolts, 139.7 mm spacing between opposite lugs)
- Center Bore: 106.1 mm
- Lug Nut Size: M12 x 1.5 (metric thread, 12 mm diameter, 1.5 mm pitch)
- Recommended Lug Nut Torque: 80–100 lb-ft
This configuration is consistent across all model years of the FJ Cruiser, from 2007 through 2022
This bolt pattern isn’t unique to the Toyota FJ Cruiser - some other Toyota models, such as the Toyota Tacoma, 4Runner, and Tundra, are using this exact pattern.
This is a good thing because it means you will be able to find aftermarket wheels and wheel parts for that bolt pattern more easily, given that several models share that bolt pattern.
Understanding Your FJ Cruiser Bolt Pattern Matters!
When buying aftermarket wheels and other wheel adaptations, matching the bolt pattern isn’t the only thing you should watch out for. Some other things, such as the offset, center bore, and load rating, are just as important.
- Even if you match the bolt pattern but ignore these other specifications, you might experience some issues.
That’s why many FJ Cruiser owners use hub-centric rings and wheel spacers to achieve the best possible fit and driving experience.
How Do You Determine Your FJ Cruiser Bolt Pattern?
Measuring the bolt pattern when you already know what it is supposed to be might seem like overkill, but this can actually come in handy.
- First, it’s always good to check and double-check your car’s specifications.
- Second, by measuring the bolt pattern on your wheels, you can spot if there are some visible but undetected issues with your wheels.
Also, it is quite easy to learn how to measure a bolt pattern. In the case of the FJ Cruiser bolt pattern, you follow these steps carefully:
- First, count how many lug holes there are on your wheel. That number will be 6, and it will be the first number in the bolt pattern.
- Then, get a measuring tape or another measuring tool and place the starting line in the middle of one lug hole.
- Then, spread the measuring tape right across the center of the wheel until you reach the opposite lug hole from where you started.
- If you measured correctly, you should get a result close to 139.7 millimeters, or 5.5 inches. Small deviations are completely fine, but if you end up with larger deviations, measure again, or check the manufacturer’s specifications and instructions.
Why Bolt Pattern Matters for Off-Roading
We mentioned earlier that FJ Cruisers are popular among pff-road drivers. If you plan to drive your FJ Cruiser off-road, then knowing your bolt pattern isn’t a matter of curiosity; it’s a necessity.
- Off-road driving places extra stress on wheels and suspension.
- Uneven terrain, rocks, and steep inclines require sturdy and well-fitted wheels.
- Using the wrong bolt pattern or installing the wheels that don’t fit may cause many issues down the road (pun intended), even wheel detachment on the trail.
That’s why knowing your bolt pattern can help you ensure your safety, both on the road and off-road. You will be able to enjoy your rides without having to worry about potential issues.
Recommended Wheel Spacers for FJ Cruiser from Orionmotors
When customizing your FJ Cruiser, you will definitely need some good wheel spacers. Here are our top picks:
OMT 6x5.5 Wheel Spacers 1.5in. For the Toyota FJ Cruiser
This Orion Motor Tech 6x5.5 (6x139.7) wheel spacer kit boosts your car’s stability and handling by widening your axle track 3 inches. It is made from T6 aircraft-grade aluminum with corrosion-resistant bolts. This makes it durable, easy to install, widely compatible, and covered with a 2-year warranty.
Conclusion
This article showed you everything you need to know about the Toyota FJ Cruiser bolt pattern, which is important info, especially if you plan to drive your FJ Cruiser off-road. By knowing this pattern, you ensure proper fitments, easy installations, and most importantly, safety.
Consider this complete guide on precise hub-centric wheel spacer installation tips that will save you time and energy.
