Are you a Toyota Tacoma driver? If so, maybe you have considered adding wheel spacers or upgrading your wheels. Many car owners and enthusiasts do this to get a more aggressive stance or a more interesting appearance for their car.
However, before you can even start to plan any modifications, you need to figure out your car’s lug pattern, as well as its bolt pattern size.
In this Toyota Tacoma Lug Pattern Guide, you will learn all about it, including some additional tips on fitting new wheels on your Tacoma.
Toyota Tacoma Lug Pattern Guide
In this table, you can see a brief overview of the Toyota Tacoma’s lug pattern and some other related information, based on your car’s generation:
| Generation | Model Years | Lug Pattern | Bolt Pattern Size | Lug Nut Thread | Center Bore |
| 1st Gen Tacoma | 1995–2004 | 6-lug | 6x139.7 mm (6x5.5") | M12x1.5 | 106.1 mm |
| 2nd Gen Tacoma | 2005–2015 | 6-lug | 6x139.7 mm | M12x1.5 | 106.1 mm |
| 3rd Gen Tacoma | 2016–2023 | 6-lug | 6x139.7 mm | M12x1.5 | 106.1 mm |
| 4th Gen Tacoma | 2024–present | 6-lug (most trims) | 6x139.7 mm | M12x1.5 | 95 mm (subject to trim) |
Lug Nut Size and Torque
Typically, Toyota Tacomas use M12X1.5 lug nuts. Recommended torque is 85–100 ft-lbs, and it depends on your wheel material. If you aren’t sure which torque to use, check the wheel manufacturer's manual.
Make sure not to overtorque or undertorque your wheels. The first can damage the studs and other wheel components. The second can reduce the safety of your car rides, and even make your wheel fall off.
Tips for Fitting Wheels on Your Toyota Tacoma
Finding new wheels for your Toyota Tacoma isn’t just about finding wheels that look good. It’s also about finding wheels that will fit perfectly into your car’s wheel hub, as well as fitting into your driving and performance goals.
So, once you have figured out the technical specifications that these wheels need to fulfill, there are also some other things you should consider.
1. Power vs Performance
First, ask yourself what you are trying to achieve with these wheels. Do you want a more powerful and aggressive stance, or do you want to improve your daily driving experience with new wheels?
2. Choose the Right Size
Next, try to use hub-centric wheels whenever possible, as they reduce vibrations and improve your car’s safety. It is important to ensure that wheel spacers are safe for your car. Don’t use wheels and wheel spacers that are too wide. This can interfere with your car’s performance, as well as with its safety.
3. Ensure Proper Installation
Before choosing to install a new set of wheels, try to understand how they will sit once installed. If they sit too inward, they can rub against other components. If they sit too far outward, this can put too much stress on your car’s steering and suspension system.
4. Check Compatibility
Finally, remember to re-check if the wheels you want to get are compatible with your car’s lug pattern and bolt pattern size. It’s always better to be safe than sorry.
Related: How to find the best wheel spacers for your car.
Summary: Which Bolt Pattern Should Toyota Tacomas Use?
With all that being said, which bolt pattern should Toyota Tacomas use? The short answer is simple. All Toyota Tacomas from 1995 to present should use a 6×139.7 mm bolt pattern with M12x1.5 lug nuts and a center bore of 106.1 mm (most trims).
Remember this or write it down, as you will need to know this every time you decide to install new wheels or various wheel modifications.
How To Choose The Best Wheel Spacers For Toyota Tacoma
When choosing the best wheel spacers for your Tacoma, you will need to make several decisions. For example, will you choose bolt-on or slip-on spacers? If you want thicker spacers, then bolt-ons are a much better option.
Next, you need to choose wheel spacers that are made of high-quality materials, such as T6 aluminum. Such wheel spacers have proven to be the most durable and resilient to daily wear and tear.
Additionally, regardless of whether you're buying new wheels, spacers, or adapters, always double-check:
- Bolt pattern - it should match your Tacoma’s bolt pattern, 6x139.7 mm
- Lug nut thread - it should be M12x1.5, and this is especially important when installing aftermarket wheels or spacers
- Offset and center bore - most Tacomas use a 106.1 mm center bore, but some more recent trims use a 95 mm center bore
- Trim-specific variations - newer models (2024 and later) often come with some specific fitments and requirements, so keep that in mind as well.
Why You Should Use Wheel Spacers on Your Toyota Tacoma
As we already mentioned, there are several reasons why car owners choose to install wheel spacers on their Tacomas. The most obvious reason is the fact that cars with wheel spacers look more aggressive and cooler.
However, a wider stance also provides a better cornering performance and reduces the body roll.
Additionally, if your car has larger tires or brake components, wheel spacers provide that much-needed clearance. In other words, they prevent rubbing between your wheels, brake components, and other parts of your car, reducing wear and tear on those parts and components.
Best Wheel Spacers for Toyota Tacoma
If you are looking to buy some wheel spacers for your Toyota Tacoma, and you want to make sure you have made the right choice, then check out these Orion Motor Tech wheel spacers:
OMT 6x5.5 Wheel Spacers for Toyota Tacoma
This wheel spacer set fits Toyota Tacoma models from 1992 to 2018. It is made from aircraft-grade T6 billet aluminum and equipped with Dacromat-coated bolts. As such, these spacers offer exceptional strength, corrosion resistance, and easy removal features:
Conclusion
In this Toyota Tacoma lug pattern guide, you can learn everything you need to know about your car’s lug pattern. If you ever decide to install new wheels, spacers, or adapters, this information will certainly come in handy.
Before making any major decision, purchase, or modification on your car, double-check everything. This way, you will ensure the safety while driving, while also enjoying an improved car performance!
